FLEXI STREAMLINE 24V 5M SINGLE COLOUR FLHB2420XX5M - 20W/M

5m roll, COB single colour, high output CRI90, 20W/m, IP20, strip width 10mm.

Application

Ideal for residential or commercial features

Design Specifications

  • 5 metre COB strip roll

  • Beam distribution 140°

  • Streamline single colour, high output COB LED technology, providing a smooth lighting profile

  • Dimming with selected driver and controls (ordered separately).

  • Heat sink required for system performance, LED channel options refer this section  - LED channel options (quick link)

  • Cuttable every 33mm

Performance

  • Dimmable - OPTIONAL
  • Dimmer Type - refer dimming options
  • WARM WHITE3000K
  • COOL WHITE4000K
  • DAYLIGHT6500K
    • Dimensions - Wiring Diagrams
    • Design Options
    • Photometric Data
    • FAQ

      Do you have any more questions? Simply check our FAQs page or contact our customer service team.


    • Downloads
    • Technical Specifications
      Product Model No. Add to Enquiry
      Use your collection cart to make an enquiry, send your collection to a friend via email, or easily download multiple datasheets with a single click
      		Input Voltage Dimmable Watts per metre Beam Angle CRI Lumens per metre LEDs Per Metre Cutting Interval CCT Body Colour Dim
      		Model No. FLHB2420WW5M Add to Enquiry Add Remove Remove Input Voltage 24 Dimmable YES Watts per metre 20 Beam Angle 140 CRI 90 Lumens per metre 1600 LEDs Per Metre 720 Cutting Interval 33 CCT 3000 Body Colour WW Dim 5000(L) x 10(W) x 1.7(H)
      		Model No. FLHB2420CW5M Add to Enquiry Add Remove Remove Input Voltage 24 Dimmable YES Watts per metre 20 Beam Angle 140 CRI 90 Lumens per metre 1700 LEDs Per Metre 720 Cutting Interval 33 CCT 4000 Body Colour CW Dim 5000(L) x 10(W) x 1.7(H)
      		Model No. FLHB2420DL5M Add to Enquiry Add Remove Remove Input Voltage 24 Dimmable YES Watts per metre 20 Beam Angle 140 CRI 90 Lumens per metre 1800 LEDs Per Metre 720 Cutting Interval 33 CCT 6500 Body Colour DL Dim 5000(L) x 10(W) x 1.7(H)
